− 76 −
(2) Device setting list
By setting the type of device, it is possible to operate according to the type.
No. Item
Setting range
/
Edit unit
Initial value
Gauge size
Gauge size of sewing machine is set.
＊
Corner knife motion is changed according to the set value of gauge
size.
＊
When
Dart stretcher is mounted, the range is limited to 8 to
12 mm.
When Breast pocket device is mounted, the range is limited
to 8 to 12 mm.
When Zipper attachment is mounted, the gauge size is
limited to the range of 16 mm and 20 mm.
8 to 20
/
2mm
10mm
Excess cut length of index on the xing side
Excess cut length of index on the xing side is set.
0.0 to
16.0mm
/
0.1mm
4.0mm
Excess cut length of index on the traveling side
Excess cut length of index on the traveling side is set.
0.0 to
16.0mm
/
0.1mm
4.0mm
To Next Page
