– 5 –
8) Put reux pipe
in the oil reservoir
A
of oil
pan
❾
. Secure the pipe in groove
.
9) Fix lter
and lter clamp
with tting
.
7) Securely attach head support rod
until its rib
is closely pressed against the table.
When it is really necessary to conduct work
with the machine head supporting rod re-
moved for the purpose of maintenance and
repair, it is necessary to carry out the work
with two or more persons.
In the case the machine head is tilted more
than necessary, oil can leak from the oil in-
let of the oil tank. It is, therefore, necessary
to remove oil from the oil tank before tilting
the machine head.
Install oil shield
❶
, supplied with the unit, on the
frame with screws
❷
.
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o and ascertaining that the motor is at rest.
❷
❶
❷
2-3. Installing the oil shield
Secure the reux pipe
as illustrated in the
gure.
❾
A
