JUKI LU-2828V-7 User Manual

– 163 –
10. SEWING SPEED TABLE
Operate the sewing machine at a speed equal to or lower than the maximum sewing speed selected from
those shown in the table below according to the sewing conditions.
Speed setting is automatically carried out according to the stitch length and alternating vertical movement
amount.
Stitch length
6 or less More than 6 and 9 or less
Amount of alternate
vertical movement of
the walking foot and presser foot
3 or less 3,500 sti/min 2,000 sti/min
More than 3 or 3.5 or less 3,400 sti/min 2,000 sti/min
More than 3.5 or 4 or less 3,200 sti/min 2,000 sti/min
More than 4 or 4.5 or less 2,900 sti/min 2,000 sti/min
More than 4.5 or 5 or less 2,600 sti/min 2,000 sti/min
More than 5 or 5.5 or less 2,400 sti/min 1,800 sti/min
More than 5.5 or 6 or less 2,200 sti/min 1,800 sti/min
More than 6 or 6.5 or less 2,000 sti/min 1,800 sti/min
More than 6.5 or 9 or less 1,800 sti/min 1,800 sti/min

JUKI LU-2828V-7 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	5 mm
Motor Type	Servo Motor
Needle Bar Stroke	36 mm
Lubrication	Automatic
Power consumption	550 W
Needle Type	DP x 17
Hook	Full Rotary Hook
