To connect to the CLI using a local management device through the console port on the
services gateway:
1. Turn off power to the services gateway.
2. Turn off power to the management device, such as a PC or laptop computer, that you
are using to access the CLI.
3. Plug one end of the Ethernet cable supplied with your services gateway into the RJ-45
to DB-9 serial port adapter supplied with your services gateway (see
Figure 20 on page 83).
4. Plug the RJ-45 to DB-9 serial port adapter into the serial port on the management
device (see Figure 20 on page 83).
5. Connect the other end of the Ethernet cable to the console port on the services
gateway (see Figure 20 on page 83).
6. Turn on the power to the management device.
7. Start an asynchronous terminal emulation application (such as Microsoft Windows
HyperTerminal), and select the appropriate COM port to use (for example, COM1).
8. Configure the port settings as shown in Table 34 on page 84.
Table 34: Port Settings for Connecting to the Console Port
ValuePort Settings
9600Bits per second
8Data bits
NoneParity
1Stop bits
NoneFlow control
9. Power on the services gateway by pressing the Power button on the front panel.
10. Verify that the Power LED on the front panel turns green.
The terminal emulation screen on your management device displays the startup
sequence. When the services gateway has finished starting up, a login prompt appears.
11. Log in as the user root. No password is required at initial connection, but you must
assign a root password before committing any configuration settings.
Related
Documentation
Connecting an SRX220 Services Gateway to the CLI Remotely on page 85•
• Performing Initial Software Configuration on the SRX220 Services Gateway Using the
CLI on page 92
• SRX220 Services Gateway Software Configuration Overview on page 77
• SRX220 Services Gateway Secure Web Access Overview on page 82
Copyright © 2016, Juniper Networks, Inc.84
SRX220 Services Gateway Hardware Guide for H Model Numbers
