Table 18: SRX320 Services Gateway Chassis Alarm Conditions and
Corrective Actions (continued)
Alarm
SeverityActionAlarm ConditionsComponent
Red
(major)
•
Contact the Juniper Networks Technical
Assistance Center (JTAC).
•
If you must replace the failed Mini-PIM,
see the SRX300 Series and SRX550 High
Memory Services Gateway Interface
Modules Reference for information about
replacing the Mini-PIMs.
A Mini-PIM has failed.Mini-PIM
Related
Documentation
Troubleshooting Resources for the SRX320 Services Gateway Overview on page 87•
• Troubleshooting the Power System on the SRX320 Services Gateway on page 89
• Using the RESET CONFIG Button on the SRX320 Services Gateway on page 90
Troubleshooting the Power System on the SRX320 Services Gateway
The LEDs on the services gateway enable you to determine the performance and
operation. The PWR LED, located on the front panel of the services gateway, indicates
the different settings with respect to the power system.
Table 19 on page 89 describes different PWR LED status settings and their corrective
actions.
Table 19: SRX320 Services Gateway Power LED Status
Possible Cause and Corrective
ActionMeaningLED Status
Normal indication. No action is required.Device is receiving power.Green
Normal indication. No action is required.Indicates that the power
button has been pressed
and quickly released.
Amber
•
Verify that the AC power cord from
the power source to the device is not
damaged. If the insulation is cracked
or broken, immediately replace the
cord or cable.
•
Ensure that the socket you plug in is
in working condition.
•
Ensure the device has an AC input
voltage between 100 and 240 VAC.
•
If you cannot determine the cause
of the problem or need additional
assistance, contact JTAC.
Indicates that the device
is not receiving power.
Off
89Copyright © 2016, Juniper Networks, Inc.
