23
PRODUCT DESCRIPTION
2.3 Product features
This instruction manual describes the power circuits of the following devices:
Device type: Drive controller
Series: COMBIVERT S6
Power range: 0.75...2.2 kW 400 V 3-phase
0.75...1.5 kW 230 V 1-phase
Housing: 2
The COMBIVERT S6 is characterized by the following features:
• For asynchronous, synchronous, IPM or synchronous reluctance motors
• With encoder or encoderless SCL and ASCL for accurate speed control
• Motor temperature monitoring PTC, KTY or PT1000
• Two-channel multi-encoder interface
• Integrated braking transistor
• Integrated brake control
• Integrated safety functionality
• Basic function STO in the compact version
• Additional high level safety in the application version
• Real-time Ethernet interfaces
• FollowingeldbussystemsaresupporteddirectlyatS6:CAN,VARAN
• RS232/485 for diagnosis or display
• Book format for space-saving control cabinet construction
• Direct mains connection for 230 V and 400 V mains, alternatively also DC input
260…750 V
• Lowleakagecurrentmainslter(<5mA)integrated,optionalwithoutlter
• High overload for best dynamics
• Supports existing machine concepts with 8 digital and 2 analog inputs, 2 digital out-
puts + 1 relay and 1 analog output 0…10 V
Due to the wide voltage range, the 3-phase 400V devices can also be operated
at 230V applications, => „5.4 UL Marking“.
