3.3.1 Installation depth

Forthevariousconnections,itisrecommendedtokeepthespecieddistance

to upstream components.

The values given are approximate values. The actual installation depth must be checked

individually by the user.

280

275

250

X2A/

X2B

X4A

X4B/

X4C

X3A/X3B

Housing 2

Dimensions All dimensions in mm

Figure 5: Installation depth

MOUNTING INSTRUCTIONS FOR CONTROL CABINET INSTALLATION
