3.4 Device data of the 400 V devices
3.4.1 Overview of the 400 V devices
The technical data are for 2/4-pole standard motors. With other pole numbers the drive
controller must be dimensioned onto the motor rated current. Contact KEB for special or
medium frequency motors.
Device size 07 09 10
Housing 2
Rated apparent output power S
out / kVA 1.8 2.8 4.0
Max. rated motor power P
mot / kW 0.75 1.5 2.2
Rated output current I
N / A 2.6 4.1 5.8
Output voltage U
out / V 0…Uin or 0…Uin_dc /√2
Output phases 3
Output frequency
1)
fout / Hz 0…599
Rated output overload (60s)
2)
I60s / % 200
Rated output overload (3s)
2)
I3s / % 250
Overcurrent
2)
IOC / % 300
Rated switching frequency f
SN / kHz 8
Rated input current I
in / A 3.6 6.0 8.0
Rated input voltage U
N / V 400
Rated input voltage UL U
N_UL / V 480
Input voltage range U
in / V 184…550
Input voltage range DC supply U
in_dc / V 260…750
Mains phases 3
Mains frequency f
N / Hz 50 / 60
Maximum current 0 Hz / 50 Hz at f
S = 4 kHz Iout_max / % 215 / 300 193 / 300 155 / 300
Maximum current 0 Hz / 50 Hz at f
S = 8 kHz Iout_max / % 162 / 300 132 / 300 103 / 275
Maximum current 0 Hz / 50 Hz at f
S = 16 kHz Iout_max / % 92 / 292 73 / 200 50 / 163
Insulation resistance @ U
_dc = 500 V Riso /MΩ > 15
DC link capacity C/μF 195 195 235
Table 9: Overview device data of the 400 V devices
1)
The output frequency is to be limited in such a way that it does not exceed 1/10 of the switching frequency.
Devices with higher max. output frequency are subject to export restrictions and are only available on re
-
quest.
2)
The values refer in % to the rated output current IN.
3.4.2 Rated operation
All rated values refer to a rated operation at UN = 400 V, rated switching frequency fSN and
an output frequency fout = 50 Hz.
