3.5.3 Voltage and frequency specications of the 230 V devices
Input voltage and frequencies
Rated input voltage U
N / V 120...230
Rated input voltage UL U
N_UL / V 120...230
Input voltage range U
in / V 184...265
Mains phases 1
Mains frequency f
N / Hz 50 / 60
Mains frequency tolerance ±f
N / Hz ±2
Table 18: Input voltages and frequencies of the 230 V devices
Input voltage for DC operation
Rated input voltage DC U
N_dc / V 325
Input voltage range DC supply U
in_dc / V 260...375
Table 19: Input voltages for DC operation of the 230 V devices
Output voltage and frequencies
Output voltage at AC supply
1)
Uout / V 3 x 0…Uin
Output voltage at DC supply
1)
Uout_dc / V 3 x 0…Uin_dc/ √ 2
Output frequency
2)
fout / Hz 0…599
Table 20: Output voltages and frequencies of the 230 V devices
1)
The voltage to the motor is dependent on the actual input voltage and the control method (=> „3.4.3.1 Ex-
ample for the calculation of the motor voltage“).
2)
The output frequency is to be limited in such a way that it does not exceed 1/10 of the switching frequency.
Devices with higher max. output frequency are subject to export restrictions and are only available on re-
quest.
DC switching level
DCswitch-o󰀨level"Error!Underpotential“
UUP_dc / V 260
DC switching level braking resistor
1)
UB_dc / V 380
DCswitch-o󰀨level"Error!Overpotential“ UOP_dc / V 420
Table 21: DC switching level of the 230 V devices
1)
The DC switching level for the braking transistor is adjustable. The default value is the value specied in the
table.
