3.4.3 Voltage and frequency specications of the 400 V devices
Input voltage and frequencies
Rated input voltage U
N / V 400
Rated input voltage UL U
N_UL / V 230 / 480
Input voltage range U
in / V 184…550
Mains phases 3
Mains frequency f
N / Hz 50 / 60
Mains frequency tolerance ±f
N / Hz ±2
Table 10: Input voltages and frequencies of the 400 V devices
Input voltage for DC operation
Rated input voltage DC U
N_dc / V 565
Rated input voltage DC UL U
N_dc_UL / V 680
Input voltage range DC supply U
in_dc / V 260…750 ±0
Table 11: Input voltages for DC operation of the 400 V devices
Output voltage and frequencies
Output voltage at AC supply
1)
Uout / V 3 x 0…Uin
Output voltage at DC supply
1)
Uout_dc / V 3 x 0…Uin_dc/√2
Output frequency
2)
fout / Hz 0…599
Table 12: Output voltages and frequencies of the 400 V devices
1)
The voltage to the motor is dependent on the actual input voltage and the control method (=> „3.4.3.1 Ex-
ample for the calculation of the motor voltage“).
2)
The output frequency is to be limited in such a way that it does not exceed 1/10 of the switching frequency.
Devices with higher max. output frequency are subject to export restrictions and are only available on request.
DC switching level
DC switching level "Error! Underpotential“
UUP_dc / V 240
DC switching level braking resistor
1)
UB_dc / V 780
DC switching level "Error! Overpotential“ UOP_dc / V 840
Table 13: DC switching level 400 V devices
1)
The DC switching level for the braking transistor is adjustable. The default value is the value specied in the table.
3.4.3.1 Example for the calculation of the motor voltage
The motor voltage for dimensioning of the drive is depending on the used components.
The mains voltage reduces according to the following table:
Components Reduction / % Example:
Mains choke U
k 4
Closed-loop drive controller with mains and motor choke
at non-rigid supply system:
400 V mains voltage - 15 % = 340 V motor voltage
Drive controller open-loop 4
Drive controller closed-loop 8
Motor choke U
k 1
Non-rigid supply system 2
Table 14: Example for the calculation of the motor voltage
35
DEVICE DATA OF THE 400 V DEVICES
