KEB COMBIVERT S6 Series User Manual

3.6.1.2 Switch-o󰀨timedependingontheoverloadat230Vdevices
Release time in s
Overload characteristic (OC Level 240%)
0
30
60
90
120
150
180
210
240
270
300
100 125 150 175 200 225
400
500
①
240
Motor current / drive controller rated currrent in %
Release time in s
Detail view in the range from 150 % to 250 %
0
5
10
150 160 170 180 190 200 210 220 230 240 250
②
Motor current / drive controller rated currrent in %
Legend
1 Thermal overload limit
2 Limitation by current controller limit (adjustable via software)
Figure 7: Switch-o time t depending on the overload I / IN (OL) 230 V devices
42
GENERAL DATA
