KEB COMBIVERT S6 Series User Manual

Frequency-dependent maximum current 230 V devices
Device size
07
Rated switching frequency
8 kHz
Output frequency f
out / Hz
0 3.1 6.2 12.5 25 50
Frequency-dependent maximum current @ fS
Basic Time Period = 62.5 µs (Parameter is22=0)
Iout_max / %
4 kHz 175
240 240
240
240
240
8 kHz 150
200 240
240
240
240
16 kHz 100
150 200
240
240
240
Frequency-dependent maximum current @ fS
Basic Time Period = 71.4 µs (Parameter is22=1)
Iout_max / %
7 kHz 156
213 240
240
240
240
14 kHz 113
163 213
240
240
240
Frequency-dependent maximum current @ fS
Basic Time Period = 83.3 µs (Parameter is22=2)
Iout_max / %
6 kHz 163
225 240
240
240
240
12 kHz 125
175 225
240
240
240
Frequency-dependent maximum current @ fS
Basic Time Period = 100 µs (Parameter is22=3)
Iout_max / %
5 kHz 169
238 240
240
240
240
10 kHz 138
188 238
240
240
240
Table 27: Frequency-dependent maximum current for device size 07 230 V devices
Device size
09
Rated switching frequency
8 kHz
Output frequency
fout / Hz
0 3.1 6.2 12.5 25 50
Frequency-dependent maximum current @ fS
Basic Time Period = 62.5 µs (Parameter is22=0)
Iout_max / %
4 kHz 157
214 240
240
240
240
8 kHz 114
171 229
240
240
240
16 kHz 86
143 200
229
240
240
Frequency-dependent maximum current @ fS
Basic Time Period = 71.4 µs (Parameter is22=1)
Iout_max / %
7 kHz 125
182 234
240
240
240
14 kHz 93
150 207
232
240
240
Frequency-dependent maximum current @ fS
Basic Time Period = 83.3 µs (Parameter is22=2)
Iout_max / %
6 kHz 136
193 239
240
240
240
12 kHz 100
157 214
236
240
240
Frequency-dependent maximum current @ fS
Basic Time Period = 100 µs (Parameter is22=3)
Iout_max / %
5 kHz 146
204 240
240
240
240
10 kHz 107
164 221
240
240
240
Table 28: Frequency-dependent maximum current for device size 09 230 V devices
