KEB COMBIVERT S6 Series User Manual

3.4.4 Input and output currents / overload of the 400 V devices
Input currents 400 V devices
Device size 07 09 10
Rated input current @ U
N = 400 V Iin / A 3.6 6.0 8.0
Rated input current UL @ U
N _UL = 480 V Iin_UL / A 2.9 4.7 6.7
Rated input current DC @ U
N_dc = 565 V
1)
Iin_dc / A 1.9 3.7 5.2
Rated input current DC UL @ U
N_UL_dc = 680 V
1)
Iin_dc_UL / A 3.6 5.8 8.0
Table 15: Input currents of the 400 V devices
1)
The values resulting from rated operation with B6 rectier circuit and mains choke 4% UK.
Output currents 400 V devices
Device size 07 09 10
Rated output current @ U
N = 400 V IN / A 2.6 4.1 5.8
Rated output current UL @ U
N _UL = 480 V IN_UL / A 2.1 3.4 4.8
Overload current (60s)
1)
I60s / % 200
Overload current (3s)
1)
I3s / % 250
Overcurrent
1)
IOC / % 300
Table 16: Output currents of the 400 V devices
1)
The values refer in % to the rated output current IN.
36
DEVICE DATA OF THE 400 V DEVICES
