OPERATION 5-7
The hydraulic oil also serves as the
transmission fluid. In cold weather,
high oil viscosity may cause low oil pres-
sure and poor circulation until the sys-
tem warms up. To prevent damage or
malfunction, allow the system to warm
up at 50% of rated engine speed accord-
ing to the following table.
AMBIENT
TEMPERATURE
Above 0 °C
(32 °F)
-10 °C ~ 0 °C
(14 ~ 32 °F)
-20 ~ -10 °C
(-4 ~ 14 °F)
Below -20 °C
(-4 °F)
TRANSMISSION OILWARM UP
REQUIRED
WARM UP TIME
At least 5 minutes
5 ~ 10 minutes
10 ~ 15 minutes
15 minutes +
IMPORTANT
Do not operate the tractor under
load until it is sufficiently warmed
up.
4. Attach the red clamp to the positive
terminal of the dead battery, and at-
tach the other end to the positive ter-
minal of the helper battery.
5. Clamp the black cable to the negative
terminal of the Engine hooks, and at-
tach the other end to the negative cable
of the helper battery.
6. If the helper battery is in another
vehicle, do not allow the tractor and
the other vehicle to touch. Start the
vehicle’s engine after connecting the
cables and let it run for a few moments.
Turn off all accessories on both
vehicles. Then start the disabled
tractor.
7. Disconnect the battery cables in the
exact opposite order as they were
attached.
C71O507B
(1) Dead Battery
(2) Lay a Damp Rag Over the Vent Caps
(3) Jumper Cables (4) Helper Battery
When jump starting the engine, follow the
instructions below to safely start the
engine.
1. Use a battery of the same voltage as
the disabled tractor to jump start the
tractor. Locate the good battery in a
safe place where the jumper cables
will reach.
2. Set the parking brake and turn the key
switch to OFF.
3. Put on safety goggles and rubber
gloves.
JUMP STARTING
WARNING
Keep sparks, open flames and
smoking materials away from bat-
teries at all times. Gases emitted
from batteries are explosive.
To Next Page
