OPERATION 5-23
SELECT REAR BALLAST CAREFULLY
Add weight to rear wheels, if needed, to
improve traction or for stability. Amount
of rear ballast should be matched to the
job; and ballast should be removed when
it is not needed. Rear wheel weights are
available, or liquid may be added to the
tires. Consult your KIOTI dealer for the
correct ballasting necessary for your
particular application.
SEVEN PIN ELECTRICAL POWER
OUTLET
C71O537B
A standard 7-pin trailer lighting socket is
provided and mounted right side of the
tractor, at the rear of the tractor.
No
1
2
3
4
5
6
7
Color of wire
W
Br
G
R
Y
B
-
Circuit
Earth
Illumination
Right turn signal
Stop
Left turn signal
Illumination
-
To Next Page
