TE1O764A
TE1O763A
(1) Oil Inlet Plug (2) Gauge
(A) Oil level is acceptable within this range
CHECKING FRONT AXLE OIL LEVEL (N1)
(1) Oil Dipstick
(A) Upper Limit (B) Lower Limit
1. Park the machine on a at surface,
lower the implement and shut off
engine.
2. Depress the brake pedals and ap-
ply the parking brake.
3. Set all shift levers into the neutral
position.
4. Stop the engine.
5. Pull out the oil dipstick, clean it,
and then insert it into its original
position. Then, pull it out again and
check if the fuel level is within the
specied range.
6. If the oil level is too low, add some
new oil so that the level is within
the allowable range. (Refer to "Lu-
brication" in the chapter "Service")
When using oil of different
maker or viscosity from the
previous one, remove all of
the old oil. Never mix two dif-
ferent types of oil.
Wipe the oil dipstick with
clean cloth or tissue.
N
ever add the oil over the up-
per limit of the tank.
•
•
•
IMPORTANT
To Next Page
