(1) Reserve Tank
(A) FULL (B) LOW
1. Check to see that the coolant level
is between the "FULL" and "LOW"
marks of recovery tank.
2. When the coolant level drops due
to evaporation, add water only up
to the full level.
In case of leakage, add anti-
freeze and water in the specified
mixing ratio up to the FULL level.
(See "Flush Cooling System and
Changing Coolant" in every 2
years maintenance)
CHECKING COOLANT LEVEL (E)
3. The tractor is furnished with a mix-
ture of anti-freeze and water in a
ratio of 50:50 which is usable in
any season.
TE1O705A
(1) Radiator Screen
(A) Detach
CLEANING GRILL, RADIATOR
SCREEN (F)
1. Check front grill and side screens
to be sure they are clean of debris.
2. Lift out the radiator screen and re-
move all the foreign material.
To avoid accidents:
Be sure to stop the engine be-
fore removing the screen.
•
CAUTION
TE1O760A
To Next Page
