Kohler Curtis F Series User Manual

2 — INSTALLATION AND WIRING
pg. 13
Return to TOC Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022
Table 4 The AMPseal Connection Protected Voltages – 23 pin controllers
Controller
Pin Number
Minimum
Reverse Voltage
Maximum
Voltage
ESD
Air Discharge
(non-contact)
Contact
(touch)
Inputs
3, 4, 5, 6, 7, 8, 9, 10, 11, 14, 15, 17, 18, 19,
21, 22, 23
Indenite short to B+ and B–
±15kV ±8kV
CAN
13, 20
Indenite short to B+ and B–
Outputs
3, 4, 5, 6, 7, 9, 10, 16, 23
Indenite short to B+ and B–
KSI
1
Indenite short to B+ and B–
Coil Supply
2
Not Protected against
short to B–
Indenite short
to B+
GND or I/O Ground
12
Not protected
Table 5 AMPSEAL Connections Protected Voltages – 35 pin controllers
Controller I/O
Pin Number
Min (reverse)
Voltage
Maximum
Voltage
ESD
Air Discharge
(non-contact)
Contact
(touch)
Inputs
8, 9, 10, 11, 12, 14, 15, 16, 17, 22, 24, 25,
26, 27, 31, 32, 33
Indenite short to B+ and B–
±15kV ±8kV
CAN (non-isolated)
21, 23, 28, 29, 34, 35
CAN (isolated)
23, 28, 29, 34, 35
Indenite short to B+ and B–
Outputs
2, 3, 4, 5, 6, 19, 20, 25, 26, 30
Indenite short to B+ and B–
KSI
1
Indenite short to B+ and B–
Coil Supply
13
Not Protected against
short to B–
Indenite short
to B+
GND or I/O Ground
7, 18
Not protected
