4 — PROGRAMMABLE PARAMETERS
pg. 37
Return to TOC Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022
MENU CHART FORMAT
Each parameter has a detailed chart ranging from the display name to a detailed description.
Interlock Input Source 0 – 32 5
[PCF]
Interlock switch assignment.
Using the available switch inputs, select the digital input
number that the interlock will use. The available switches
depends upon the controller and application. For example,
Switch 5 (pin 9) = INTERLOCK in Figure 13.
Set this parameter to 0 to allow VCL control of interlock.
To enable interlock with KSI turn-on, set the input source
to switch 20 (the Keyswitch Input).
Switch_20 = CAN Index 0x3339 0x00
Interlock_Input_Source 0 – 32
0x34B2 0x00
Parameter name
as it appears in the
Programmer
VCL Parameter_
Name
CAN Object index
and sub-index
Allowable range in the
Programmer’s units
Description of parameter’s function and,
where applicable, suggestions for setting it.
TERMINOLOGY
When setting parameters and commissioning the vehicle, follow these denitions.
CiA/CANopen CAN in Automation (CiA) is the international users’ and
manufacturers’ group for the CAN network (Controller Area
Network), internationally standardized in the ISO 11898 series.
CANopen is a CAN-based communication system. e CANopen
design was originally for motion-oriented machine control systems,
such as factory handling system.
Today, CANopen sees usage in various application elds, such as medical
equipment, o-road vehicles, maritime electronics, railway applications, or
building automation. References include CiA 301, 303-1, etc.
e Curtis controllers are designed to use the CANopen features.
Curtis Integrated
Toolk it
e Curtis Integrated Toolkit
TM
(CIT) is a Curtis Instruments developed
soware program for conguring and communicating with Curtis
Instruments products. Use CIT to program (change and edit parameters,
etc.) the Controller. See Appendix D for programming, monitoring, and
diagnostic soware and toolsets.
I/O Input/Output. I/O generally refers to the controller AMPSEAL
connector’s input signals or switches, output signals, power, or low-
side drivers. Controllers with different AMPSEAL pin-counts have
different I/O assignments.
Object Index e object dictionary is essentially a table that stores conguration and
process data. e CANopen standard denes a 16-bit index and an 8-bit
sub-index. e object dictionary is the method by which CANopen
devices communicate. Every parameter and monitor variable has its own
unique CAN Object Index. e parameter and monitor tables list each
item’s CAN Object Index.
Allowable range
in VCL units.
Default value
PCF parameter
