85Section 5 Decision-Makerr 550 ControllerTP-6356 4/12
5.3.7 User-Defined Settings (Code Version 2.10 or Higher)
Use the table below to record user-defined settings
during the generator set controller setup and calibration.
The controller default settings and ranges provide
guidelines. The table contains all faults with ranges and
time delays including items that do not have
adjustments.
Note: Inhibit time delay is the time delay period after
crank disconnect.
Note: The engine ECM may limit the crank cycle even if
the controller is set to a longer time period.
Status Event
or Fault
Refer
to
Menu
Digital Display
Relay
Driver
Output
(RDO)
Range Setting
Default
Selection
Inhibit
Time
Delay
(sec.)
Time
Delay
(sec.)
User-Defined
Settings
Access Code
(password)
14 User-Selectable 0(zero)
AC Sensing Loss 10 AC SENSING
LOSS
RDO-25 * Not adjustable
Air Damper Control
(if used) **
10 Not adjustable
Air Damper Indicator
(if used), see D20 **
—
Air/Fuel Module
(AFM) Engine Start
Delay ]
10 AFM ENG
START DELAY
Fixed Not adjustable
Air/Fuel Module
(AFM) Remote
Start]
10 AFM REMOTE
START
RDO-25 ]
Not adjustable
Air/Fuel Module
(AFM) Shutdown
(see D11) ]
Not adjustable
Alternator Protection
Shutdown
10 ALTERNATOR
PROTECTION
Not adjustable
Analog Aux. Input 0 9 LOCAL BATT
VDC
Fixed Not adjustable
Analog Aux. Inputs
A01--A07
9 USER-DEFINED
A01--A07
Default Values with
Warning Enabled:
HI warning 90%
LO warning 10%
HI shutdown 100%
LO shutdown 1%
30 sec.
inhibit,
5 sec. delay
0--60 0--60
Analog Aux. Input
A01 (non-ECM only)
9 A01
COOLANT
TEMP
Default Values with
Warning Enabled:
HI/LO warning and
HI/LO shutdown are
all engine dependent
30 sec.
inhibit,
0 sec. delay
warning,
5 sec. delay
shutdown
Not adjustable
Analog Aux. Input
A02 (non-ECM only)
9 A02
OIL
PRESSURE
Default Values with
Warning Enabled:
HI/LO warning and
HI/LO shutdown are
all engine dependent
(255 psi max.)
30 sec.
inhibit,
0 sec. delay
warning,
5 sec. delay
shutdown
Not adjustable
Analog Aux. Input
A03 ]
9 A03
INT AKE AIR
TEMP
Default Values with
Warning Enabled:
HI/LO warning are
all engine dependent
30 sec.
inhibit,
0 sec. delay
warning
Not adjustable
Analog Aux. Input
A04 *
9 A04
FUEL LEVEL
Default Values with
Warning Enabled:
HI/LO warning are
engine dependent
30 sec.
inhibit,
0 sec. delay
warning
Analog Aux. Input
A04 ]
9 A04
OIL TEMP
Default Values with
Warning Enabled:
HI/LO warning are
engine dependent
30 sec.
inhibit,
0 sec. delay
warning
Not adjustable
* All models, except Waukesha-powered models. ** NFPA applications
[ Non-paralleling applications [[ DDC/MTU engine with MDEC/ADEC
] Waukesha-powered models ]] FAA only
w Paralleling applications
