Testing engine oil pressure 1
a Testing tools for engine oil pressure
1. Open the pump room cover and disconnect
outlet hose (1) of the engine oil filter.
2. Install adapter E3 and connect the discon-
nected hose again.
3. Install nipple E4 and connect it to hydraulic tes-
ter E2.
4. Start the engine and heighten the engine cool-
ant temperature to the operating range.
5. Test the oil pressure during low idle and high
idle.
6. After finishing test, remove the Testing tools
and return the removed parts.
Symbol Part No. Part name
E
1
799-101-5002 Hydraulic tester
790-261-1204 Digital hydraulic tester
2 799-401-2320 Gauge
3
799-401-3500 Adapter (Size: 06)
02896-11018 O-ring
4
799-101-5220 Nipple (10 x 1.25 mm)
07002-11023 O-ring
