SEN03768-01 01 Specification
4 PC130-8
Specifications 1
The values are based on the machine with the triple grouser shoe.
Machine model
PC130-8
Standard specification
Serial No. 80001 and up
Bucket capacity
m
3
0.50
Operating weight kg 12,700
Performance
Working ranges
Max. digging depth mm 5,520
Max. vertical wall depth mm 4,980
Max. digging reach mm 8,290
Max. reach at ground level mm 8,170
Max. digging height mm 8,650
Max. dumping height mm 6,210
Maximum digging force (bucket) kN{kg} 93.4{9,520}
Swing speed rpm 11.0
Swing max. slope angle Degree 20.0
Travel speed (Low/High) km/h 2.9/5.5
Gradeability deg. 35
Ground pressure
kPa{kg/cm
2
}
39.9{0.41}
Dimension
Overall length (for transport) mm 7,590
Overall width mm 2,500
Overall height (for transport) mm 2,875
Overall height (for work) mm 2,855
Ground clearance of counterweight mm 895
Min. ground clearance mm 400
Tail swing radius mm 2,190
Min. swing radius of work equipment mm 2,450
Height of work equipment at min.
swing radius
mm 6,495
Crawler overall width mm 2,490
Crawler overall length mm 3,610
Length of track on ground mm 2,880
Track gauge mm 1,990
Overall height of machine cab mm 2,855
