SEN03768-01 01 Specification
8 PC130-8
List of weights 1
k This weight table is prepared for your reference when handling or transporting the components.
Unit: kg
Machine model
PC130-8
Standard specification
Serial No. 80001 and up
Engine assembly (excl. water, oil) 461
• Engine (excl. water, oil) 332
• Engine mount 21.5
•PTO 5.5
• Hydraulic pump 102
• • Filter (for KA specification) (6 x 2)
Cooling assembly (excl. coolant, oil) 96.1
• Radiator (excl. coolant) 9.2
• Oil cooler (excl. oil) 11.0
• Aftercooler 7.5
• Fuel cooler (excl. fuel) 0.53
Revolving frame 1,190
Operator cab 480
Operator seat 35
Fuel cooler (excl. fuel) 105
Hydraulic tank (excl. hydraulic oil) 97
Control valve 95
Counterweight 2,455
Swing motor (incl. brake valve) 20
Swing circle 153
Swing machinery 71.6
Center swivel joint 28.6
Track frame assembly (excl. track shoe) 2,300
• Track frame 1,305
• Idler assembly 79 x 2
• Recoil spring assembly 69 x 2
• Carrier roller 16.5 x 2
• Track roller 22 x 14
• Travel motor (with reduction gear) 145 x 2
•Sprocket 33.1 x 2
Track shoe assembly
• Triple grouser shoe (500 mm) 755 x 2
• Triple grouser shoe (600 mm) 815 x 2
• Triple grouser shoe (700 mm) 905 x 2
• Road liner (500 mm) 780 x 2
