MAINTENANCE EVERY 100 OPERATING HOURS

7-44

MAINTENANCE EVERY 100 OPERATING HOURS

All maintenance operations to be performed after 10 and 50

hours of operation fall also into this maintenance category.

DRAINING THE WATER SEPARATOR, REMOVING WATER AND DIRT DE-

POSITS

Keep a container ready for collecting the liquid from the water

separator (1).

1. Screw out the drain plug (2).

2. Let the water run off.

3. Screw in the drain plug and tight it.

4. Check for tightness.

75_231
