CONTROLS AND INDICATORS
4-28
ARTICULATED STEERING CATCH
The articulated steering catch is used to join rigidly the front and
rear part of the machine, thus preventing the articulated steering
from bending. You must block the articulated steering before the
machine is hoisted or before repairs or maintenance operations
are being performed.
TRACTION DEVICE
You can use the traction device (hitch) to tow off, e.g., another
machine or trailer. You must also fix the machine at the tie bolt
during transport. Always secure the bolt of the traction device,
which is fixed to a chain, with the spring bolt.
SOCKET
• Danger of accidents!
Electrical devices may interfere with the on-board elec-
tronics. For this reason, connect only the working lamp to
the socket.
You may connect a working lamp to the socket (1).
75_155
1
2
75_04
8
1
