LOADING AND TRANSPORTING THE MACHINE
2-5
SECURING THE MACHINE DURING TRANSPORT
• If the machine is insufficiently secured, it may start to skid
or fall off the transport vehicle and cause severe acci-
dents!
Always secure the machine with ropes and wheel chocks
or wedges to avoid falling down and skidding.
• Stay wire ropes that are incorrectly attached may damage
the machine!
Only fasten the eye hooks of the stay wire ropes at the
marked attachment points.
When the machine is on the loading area of the transport vehi-
cle, secure the articulated steering as described in the chapter
"Securing the Articulated Steering". Then, block the wheels of
the machine with wheel chocks or wedges and secure the ma-
chinewithwireropesinsuchawaythatitwillneitherstartto
skidnortipoverduringtransport.Toavoiddamagetothema-
chine, only fasten the eye hooks of the stay wire ropes at the
marked attachment points. The attachment points to be used are
the two eye hooks at the front frame and the tie bolt at the rear
frame of the machine. The positions of the attachment points are
shown in the figure on the previous page.
AFTER TRANSPORT
After transport, remove all securing devices, such as wheel
chocks or wedges and wire ropes. Remove the catch of the ar-
ticulated steering before you drive the machine off the transport
vehicle. For this purpose, reverse the steps 1 through 4 de-
scribed in the chapter "Securing the Articulated Steering".
