USE OF THE MACHINE AND RELATED CONTROLS
118
WEAM009300
3.3.5 HOW TO MOVE THE MACHINE
WARNING
q Before moving the machine, make sure that you perfectly know the control functions and all the relevant
safety regulations.
q The operator must be seated in the driving position with fastened seat belt.
q Before operating the travel levers, check the direction of the undercarriage. If the sprocket is at the front,
the operation of the travel levers is inverted.
q Before moving the machine, make sure that there is no one within its operating range and that there are
no obstacles in the surrounding area.
q Be extremely careful when reversing, and make sure that there are no persons, other equipment or
obstacles in the way.
q Avoid any travel manoeuvre or change of direction with the accelerator at maximum speed, since
manoeuvres carried out in these conditions may cause abrupt and dangerous movements.
q Make sure that the travel alarm functions correctly.
q Do not use the speed increase function when changing direction or carrying out a counter-rotation.
3.3.5.1 PRELIMINARY OPERATIONS TO BE
CARRIED OUT BEFORE MOVING THE
MACHINE
1. Pull the accelerator lever (1) towards the max. speed position
to increase the engine speed.
(A): idling
(b): max. speed
3.3.5.2 MOVING THE MACHINE FORWARD
1. Move the safety lever (2) to working position (F), then lift the
working tools 40-50 cm off the ground.
2. Lift the blade.
3. Opearate both travel levers (3) as explained below.
RKA16480
RKA22950
RKA01610
