AUTHORISED TOOLS
230
WEAM009300
6.1.3 AUTHORISED TOOLS CHARACTERISTICS
CAUTION
q Only use tools authorised by Komatsu.
q Pay special attention to the safety standards and, before starting operations, carry out a test (in a safe
place) to check the operative range of the tool and its centre of gravity.
q Some tools, when completely retracted, can interfere with some parts of the machine (specially with the
operator's cab). Consequently, pay special attention to avoid any interference.
6.1.3.1 AUTHORISED TOOLS CHARACTERISTICS
a Measure referred to the tool diameter
q Measure referred to the tool length
NOTE
q Tools total weight with loaded material and any quick attachment should not exceed the value of the lifting
capacity.
Total weight = Bucket weight (+ a quick attachment) + [capacity x material density].
q The standard specific gravity is 1.8 t/m
3
EQUIPMENT
MAX. DIMENSIONS
MAX. OPERATING
PRESSURE
(bar)
MAX.
FLOW RATE
(l/min.)
Width (mm) Height
(mm)
Backhoe bucket
400 – – –
Ditch-cleaning bucket
1000 – – –
Ditch-digging bucket
800 – – –
Clamshell bucket
250 900 150 20
Hydraulic breaker
– 815 120 23
÷40
Drill
a
200
a
1000 150 25
MAXIMUM WEIGHT ALLOWED (kg)
Standard 880-mm boom and
standard counterweight
Long 1130-mm boom and standard
counterweight
Long 1130-mm boom and additional
counterweight
140 kg 120 kg 150 kg
