TECHNI
CAL DA
T
A
220
WEAM009300
5.1
TECHNICAL DA
T
A
Unit of measurement
PC14R-2
T
are with roof
(Operator included: 80 kg)
(kg)
1440
T
are with cab
(Operator included: 80 kg)
(kg)
1590
Bucket capa
city
(m3)
0,044
Engine
-
Komatsu
3D67E-2A
diesel engine
Engine power
KW (HP)/rpm
1
1,2(15)/2
600
A -
T
otal length
mm
3380
B-
T
otal height
mm
2320
C
T
otal width
mm
1000
D -
T
r
ack width
mm
230
E
Swing radi
us
mm
825
F
T
otal length of the tracks
mm
1370
G -
T
umbler distance
mm
1015
Min. ground clearan
ce
mm
205
T
ravel speed
km/h (MPH)
2,0 (1,2)
Swing speed
rpm
8,9
221
