PRODUCT IDENTIFICA
TION
WEAM009300
7
1.4.3
ENGINE SERIAL NUMBER AND
EXHAUST GAS EMISSION PLA
TE
The engine serial n
umber is stam
ped on the plate positioned o
n
the engine itself.
The exhaust gas emission plate is applied to the counterweigh
t.
1.4.4
TRA
VEL REDUCTION GEAR SERIAL
NUMBER
The serial number
is stamped on the pla
te positioned inside th
e
travel reduction gear and can be seen af
ter removing th
e cover
(1).
RKA16540
RKA16550
RKAB5060
1
8
10
