Using the APS Adapter AD-10 (sold separately)
APS (Advanced Photo System) cassette film can be scanned using the APS Adapter AD-10. The
cassette must contain processed film; the square number 4 mark at the end of the cassette
should be highlighted in white. Do not load unprocessed film.
To load an APS cassette, slide the film-cham-
ber release (1) towards the top of the adapter
unit until the chamber door opens (2). The
film-chamber release will not return to its
original position until the door is closed.
Insert the cassette into the film chamber as
shown (3). Close the chamber door (4); the
film-chamber release will return to its original
position (5).
When the indicator lamp glows steadily, open
the front door until the top of the door is
aligned with the APS film-holder mark.
With the scanner contacts face up, insert the
adapter into the scanner until it stops. The
scanner detects the holder and automatically
loads the film. Do not remove the holder until
the film has been rewound, see page 21.
When using the APS adapter, if the scanner makes a strange sound or the film-advance warning
appears, eject the APS adapter immediately (p. 21) and do not reinsert it. Contact a Konica
Minolta service facility.
20 Loading the film holders
1
2
3
5
4
