23 TECHNICAL DATA 258

Screw, timing chain tensioner release M10x1 10 Nm (7.4 lbf ft) –

Spark plug M10x1 15 Nm (11.1 lbf ft) –

Cylinder head screw M11x1.5 Tightening sequence:

Using a crisscross pattern

Step 1

15 Nm (11.1 lbf ft)

Step 2

30 Nm (22.1 lbf ft)

Step 3

90°

Step 4

90°

Lubricated with engine oil

Coolant temperature sensor M12x1.5 12 Nm (8.9 lbf ft) –

Rotor screw M12x1.5 90 Nm (66.4 lbf ft) –

Spark plug M12x1.5 15 Nm (11.1 lbf ft) –

Nut of engine sprocket M20x1.5 100 Nm (73.8 lbf ft) Loctite

243™

Oil drain plug M20x1.5 20 Nm (14.8 lbf ft) –

Nut, inner clutch hub M22x1.5 120 Nm (88.5 lbf ft) Loctite

243™

Plug, timing-chain tensioner M24x1.5 25 Nm (18.4 lbf ft) –

Screw in alternator cover M24x1.5 8 Nm (5.9 lbf ft) –

Nut, primary gear M33LHx1.5 130 Nm (95.9 lbf ft) Loctite

243™

23.3 Capacities

23.3.1 Engine oil

Engine oil 3.60 l (3.8 qt.) External temperature: ≥ 0 °C

(≥ 32 °F)

Engine oil (SAE 10W/50)

( p. 268)

KTM 1190 RC8 R User Manual
