23 TECHNICAL DATA 261

23.5 Electrical system

Battery YTZ14S Battery voltage: 12 V

Nominal capacity: 11.2 Ah

maintenance-free

Fuse 58011109130 30 A

Fuse 75011088015 15 A

Fuse 75011088010 10 A

Low beam / high beam H7 / base PX26d 12 V

55 W

Parking light LED

Instrument lights and control lamps LED

Turn signal LED

Brake/tail light LED

License plate lamp W5W / base W2.1x9.5d 12 V

5 W

23.6 Tires

Front tires Rear tires

120/70 ZR 17 M/C 58W TL

Continental Conti SportAttack 2

190/55 ZR 17 M/C 75W TL

Continental Conti SportAttack 2

Additional information is available in the Service section under:

http://www.ktm.com
