CONTROLS 14
5.10Light switch (EXC, EXC SIX DAYS)
B00082-10
The light switch is fitted on the left side of the handlebar.
Possible states
Light off – Light switch is turned to the right. In this position, the light
is switched off.
Low beam on – Light switch is in the central position. In this position,
the low beam and tail light are switched on.
High beam on – Light switch is turned to the left. In this position, the
high beam and the tail light are switched on.
5.11Light switch (XC-W)
500146-10
Light switch is located to the right of the speedometer.
Possible states
• The light switch has no function when the vehicle is delivered – It can be used to
retrofit the vehicle with a lighting system.
5.12Horn button (EXC, EXC SIX DAYS)
B00083-10
The horn button is fitted on the left side of the handlebar.
Possible states
• Horn button in neutral position
• Horn button pressed – The horn is operated in this position.
5.13Turn signal switch (EXC, EXC SIX DAYS)
B00088-10
Turn signal switch is fitted on the left side of the handlebar.
Possible states
Turn signal off – The turn signal switch is in the central position.
Left turn signal, on – The turn signal switch is turned to the left.
Right turn signal, on – The turn signal switch is turned to the right.
5.14Overview of indicator lamps (EXC, EXC SIX DAYS)
500147-01
Possible states
High beam indicator lamp lights up blue – High beam is switched on.
Turn signal indicator lamp flashes green – Turn signal light is switched
on.
