MAINTENANCE WORK ON CHASSIS AND ENGINE 82
B00039-10
– Detach air filter holder at the bottom and swing it to one side. Remove the air
filter with the air filter support.
– Remove the air filter from the air filter support.
11.96Installing the air filter x
301262-10
– Mount the clean air filter onto the air filter support.
– Grease the air filter in area .
Long-life grease ( p. 132)
B00039-10
– Put in both parts together, position them, and fix them with air filter holder .
Info
If the air filter is not correctly mounted, dust and dirt can penetrate into the
engine and can cause damage.
– Install the air filter box lid. ( p. 81)
11.97Cleaning the air filter x
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Oil, grease, filters, fuel, cleaners, brake fluid, etc., should be disposed of as stipulated in applicable regulations.
Info
Do not clean the air filter with fuel or petroleum since these substances attack the foam.
–
Remove the air filter. x ( p. 81)
– Wash the air filter thoroughly in special cleaning liquid and allow it to dry properly.
Air filter cleaner ( p. 132)
Info
Only press the air filter to dry it; never wring it out.
– Oil the dry air filter with a high quality filter oil.
Oil for foam air filter ( p. 132)
– Clean the air filter box.
– Check the carburetor connection boot for damage and tightness.
–
Install the air filter. x ( p. 82)
