CONTROLS 23
7.5Choke (EXC EU, EXC SIX DAYS)
500136-10
The choke lever is fitted on the left side of the handlebar.
Activating the choke function frees an opening through which the engine can draw
extra fuel. This gives a richer fuel-air mixture, which is needed for a cold start.
Info
If the engine is warm, the choke function must be deactivated.
Possible states
• Choke function activated – The choke lever is pulled to the stop.
• Choke function deactivated – The choke lever is pushed back to the stop.
7.6Shift lever
B00005-10
Shift lever is mounted on the left side of the engine.
B00005-12
(All 125/150/200 models)
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
B00005-11
(All 250/300 models)
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
7.7Kickstarter
B00006-10
The kickstarter is fitted on the right side of the engine. The top part can be
swiveled.
