CONTROLS 24
7.8Foot brake lever
B00007-10
Foot brake lever is located in front of the right footrest.
The foot brake lever is used to activate the rear brake.
7.9Side stand
B00085-10
Note
Danger of damage The parked vehicle may roll away or fall over.
– Always place the vehicle on a firm and even surface.
Note
Material damage Damage and destruction of components by excessive load.
– The side stand is designed for the weight of the motorcycle only. Do not sit on the
motorcycle when it is supported by the side stand only. The side stand and/or the
frame could be damaged and the motorcycle could fall over.
To park the motorcycle, press side stand to the ground with your foot and lean the
motorcycle on it.
B00086-10
When you are riding, side stand must be folded up and secured with rubber
band .
7.10Steering lock (EXC, EXC SIX DAYS)
B00084-10
Steering lock is fitted on the left side of the steering head.
The steering lock is used to lock the steering. Steering, and therefore riding, is no
longer possible.
7.11Locking the steering (EXC, EXC SIX DAYS)
Note
Danger of damage The parked vehicle may roll away or fall over.
– Always place the vehicle on a firm and even surface.
