SERVICE WORK ON THE CHASSIS 13

253

F02063-10

–

Remove screws

4

and engine guard

5

.

13.34 Installing the engine guard

F02063-11

–

Position engine guard

1

.

–

Mount screws

2

, but do not tighten yet.

Guideline

Screw, engine

guard

M6x10 10 Nm (7.4 lbf ft)

Loctite

®

243™
