TECHNICAL DATA 23

375

Full payload 5 clicks

Spring preload - Preload Adjuster

Comfort 4 turns

Standard 4 turns

Sport 4 turns

Full payload 10 turns

Fitted length 380 mm (14.96 in)

Spring length 210 mm (8.27 in)

Spring rate

Weight of rider: 75 … 85 kg (165 … 187 lb.) 95 N/mm (542 lb/in)

Gas pressure 16 bar (232 psi)

Damper oil Shock absorber fluid (SAE 2.5)

(50180751S1) ( p. 393)

23.8.2 890 ADVENTURE R RALLY

Shock absorber article number 12.18.0S.10

Shock absorber WPXPLOR PRO 7746

Low-speed compression damping

Comfort 15 clicks

Standard 12 clicks

Sport 10 clicks
