COMBINATION INSTRUMENT 7
67
7.1 Combination instrument
F01763-10
The combination instrument is attached in front of the handlebar.
The combination instrument is divided into two function areas.
1
indicator lamps ( p. 72)
Display
2
7.2 Activation and test
F03307-01
Activation
The combination instrument is activated when the ignition is
switched on.
Info
The brightness of the displays is controlled by an ambient
light sensor in the combination instrument.
Test
The welcome text appears on the display and all indicator lamps
are briefly activated for a function check.
