23 TECHNICAL DATA

372

Sport 10 clicks

Full payload 15 clicks

Spring preload - Preload Adjuster

Comfort +0

Standard +0

Sport +0

Full payload +3

Spring length with preload spacer(s) 464 mm (18.27 in)

Spring rate

Weight of rider: 75 … 85 kg (165 … 187 lb.) 6.7 N/mm (38.3 lb/in)

Fork length 912 mm (35.91 in)

Fork oil per fork leg 630 ± 5 ml (21.3 ± 0.17 fl. oz.) Fork oil (SAE 4) (48601166S1)

( p. 393)

23.7.2 890 ADVENTURE R RALLY

Fork article number 14.18.2S.10

Fork WPXPLOR PRO 7548

Compression damping

Comfort 16 clicks

Standard 20 clicks

Sport 10 clicks

Default Chapter5
