23 TECHNICAL DATA

374

Oil capacity, cartridge 170 ml (5.75 fl. oz.) Fork oil (SAE 4) (48601166S1)

( p. 393)

23.8 Shock absorber

23.8.1 890 ADVENTURE R

Shock absorber article number 0637C454U305000

Shock absorber WPXPLOR 5746

Low-speed compression damping

Comfort 20 clicks

Standard 15 clicks

Sport 10 clicks

Full payload 7 clicks

High-speed compression damping

Comfort 2 turns

Standard 1.5 turns

Sport 1 turn

Full payload 0.5 turns

Rebound damping

Comfort 23 clicks

Standard 15 clicks

Sport 12 clicks

Default Chapter5
- Table of Contents5
1 Means of Representation 113
- Symbols Used13
- Formats Used14
2 Safety Advice 215
- Use Definition - Intended Use15
- Misuse15
- Degrees of Risk and Symbols16
- Overview of Labels18
- Reporting Safety Defects24
- Noise Emission Warranty25
- Operating Noise Warning25
- Manufacturer Warranty for the Exhaust Monitoring System25
- Consumer Rights26
- Tampering Warning27
- Safe Operation28
- Protective Clothing29
- Work Rules29
- Environment30
- Owner's Manual30
3 Important Notes32
- Manufacturer Warranty, Implied Warranty32
- Fuel, Auxiliary Substances32
- Spare Parts, Technical Accessories32
- Service33
- Figures33
- Customer Service33
4 View of Vehicle34
- View of Vehicle, Front Left (Example)34
- View of Vehicle, Rear Right (Example)36
5 Serial Numbers38
- Vehicle Identification Number38
- Type Label39
- Key Number40
- Engine Number40
- Fork Part Number41
- Shock Absorber Article Number41
- Steering Damper Article Number42
6 Controls 643
- Clutch Lever43
- Hand Brake Lever43
- Throttle Grip44
- Switches on the Left Side of the Handlebar44
- Combination Switch44
- Light Switch45
- Cruise Control System Tip Switch46
- Menu Buttons49
- Turn Signal Switch50
- Horn Button51
- Switches on the Right Side of the Handlebar51
- Start Button/Emergency off Switch51
- Ignition and Steering Lock52
- Locking the Steering53
- Unlocking the Steering54
- Socket for Electrical Accessories54
- Opening the Fuel Tank Filler Cap55
- Closing the Fuel Tank Filler Cap57
- Fuel Cocks58
- Opening the Storage Compartment on the Left58
- Closing the Storage Compartment on the Left60
  - Opening the Storage Compartment on the Right61
  - Closing the Storage Compartment on the Right62
  - Tool Set63
  - Grab Handles63
  - Luggage Rack Plate64
  - Seat Lock65
  - Passenger Foot Pegs65
  - Shift Lever66
  - Foot Brake Lever67
  - Side Stand67
7 Combination Instrument 769
- Activation and Test69
- Day-Night Mode71
- Warnings72
- Ice Warning72
- Indicator Lamps74
- Display78
- Rally Display (Optional)82
- Speed83
- Shift Warning Light84
- Speedometer85
- Heated Grip (Optional)86
- Seat Heater (Optional)86
- Ride Display87
- ABS Display87
- MTC Display88
- Cruise Control Indicator (Optional)88
- Coolant Temperature Indicator89
- Fuel Level Display90
- Ambient Air Temperature Indicator92
- Time92
- Favorites Display93
- Quick Selector 1 Display93
- Quick Selector 2 Display94
- Navigation Display94
- Menu95
- Ktm My Ride95
- Audio96
- Navigation98
- Pairing99
- Phone100
- Headset103
- Telephony105
- Trips/Data106
- General Info107
- Trip 1108
- Trip 2109
- TPMS (Function Optional)110
- 7.26.13 Warning111
- 7.26.14 Ride Mode112
- Ride Mode113
- Rally (Optional)115
- Throttle Response (Optional)116
- Leave Rally (Optional)117
- 7.26.19 Motorcycle118
- 7.26.20 Mtc119
- MTC+MSR (Optional)120
- 7.26.22 Abs122
- Heating Grip (Function Optional)123
- Heating Seat Rider (Function Optional)124
- Quick Shift+ (Optional)125
- 7.26.26 Settings125
- 7.26.27 Favorites126
- Quick Selector 1127
- Quick Selector 2128
- 7.26.30 Bluetooth129
- 7.26.31 Display Theme130
- 7.26.32 Shift Light131
- 7.26.33 Rpm1131
- 7.26.34 Rpm2132
- 7.26.35 Shift Light133
- 7.26.36 Setting the Time and Date133
  - 7.26.37 Drl136
  - 7.26.38 Units138
  - 7.26.39 Distance138
  - 7.26.40 Temperature139
  - 7.26.41 Fuel Cons139
  - 7.26.42 Language140
  - Heating (Optional Function)141
  - Heating Grip (Function Optional)142
  - Heating Seat Rider (Optional Function)143
  - Heating Seat Pillion (Function Optional)144
  - 7.26.47 Service145
  - 7.26.48 Extra Functions146
8 Ergonomics 8147
- Handlebar Position147
- Adjusting the Handlebar Position147
- Adjusting the Windshield150
- Adjusting the Basic Position of the Clutch Lever152
- Adjusting the Basic Position of the Hand Brake Lever153
- Adjusting Foot Brake Lever Stub154
- Adjusting the Basic Position of the Foot Brake Lever155
- Checking the Basic Position of the Shift Lever157
- Adjusting the Basic Position of the Shift Lever158
9 Preparing for Use160
- Advice on Preparing for First Use160
- Running in the Engine162
- Loading the Vehicle163
10 Riding Instructions166
- Checks and Maintenance Measures When Preparing for Use166
- Starting the Vehicle167
- Starting off168
- Quickshifter + (Optional)169
- Shifting, Riding170
- MSR (Optional)176
- Applying the Brakes177
- Stopping, Parking179
- Transporting181
- Refueling182
11 Service Schedule 11185
- Additional Information185
- Required Work185
- Recommended Work188
12 Tuning the Chassis 12189
- Fork/Shock Absorber189
- Adjusting the Compression Damping of the Fork189
- Adjusting the Rebound Damping of the Fork192
- Adjusting the Spring Preload of the Fork194
- Bleeding the Fork Legs (890 ADVENTURE R RALLY)196
- Compression Damping of the Shock Absorber197
- Adjusting the Low-Speed Compression Damping of the Shock Absorber198
- Adjusting the High-Speed Compression Damping of the Shock Absorber200
- Adjusting the Rebound Damping of the Shock Absorber203
- Adjusting the Spring Preload of the Shock Absorber205
13 Service Work on the Chassis 13209
- Raising the Motorcycle with Rear Lifting Gear209
- Removing the Rear of the Motorcycle from the Lifting Gear209
- Lifting the Motorcycle with the Front Lifting Gear210
- Taking the Motorcycle off the Front Lifting Gear211
- Removing the Seat212
- Mounting the Seat213
- Checking for Chain Dirt213
- Cleaning the Chain214
- Checking the Chain Tension216
- Adjusting the Chain Tension218
- Checking the Chain, Rear Sprocket, Engine Sprocket, and Chain Guide220
- Removing the Left Side Cover224
- Installing the Left Side Cover225
- Removing the Right Side Cover226
- Installing the Right Side Cover227
- Removing the Battery Cover228
- Installing the Battery Cover229
- Removing Left Fuel Tank Spoiler230
- Installing the Left Fuel Tank Spoiler233
- Removing Right Fuel Tank Spoiler235
- Installing the Right Fuel Tank Spoiler238
- Removing the Front Fender240
- Installing the Front Fender241
- Mount Screws , but Do Not Tighten yet241
- Guideline241
- Removing Fork Protector242
- Installing the Fork Protector242
- Mount Screw 5 , but Do Not Tighten yet242
- Cleaning the Dust Boots of the Fork Legs243
- Removing the Windshield246
- Installing the Windshield247
- Removing Left Fuel Tank Cover248
- Installing the Left Fuel Tank Cover249
- Guideline Screw, Fuel Tank M6249
- Guideline249
- Screw, Fuel Tank M6249
- Removing Right Fuel Tank Cover251
- Installing the Right Fuel Tank Cover252
- Removing Engine Guard253
- Installing the Engine Guard255
- Removing the Main Silencer257
- Installing the Main Silencer259
14 Brake System264
- Anti-Lock Braking System (ABS)264
- Checking Brake Discs267
- Checking the Front Brake Fluid Level268
- Adding Front Brake Fluid269
- Checking the Front Brake Linings272
- Checking the Free Travel of the Foot Brake Lever273
- Checking the Rear Brake Fluid Level274
- Adding Rear Brake Fluid275
- Checking the Rear Brake Linings278
15 Wheels, Tires 15279
- Removing the Front Wheel279
- Installing the Front Wheel284
- Removing the Rear Wheel292
- Installing the Rear Wheel295
- Checking the Rear Hub Damping Rubber Pieces298
- Checking the Tire Condition300
- Checking Tire Pressure302
- Checking Spoke Tension304
- Tubeless Tire System305
- Using Tire Repair Spray306
16 Electrical System 16307
- Daytime Running Light (DRL)307
- Removing the 12-V Battery308
- Installing the 12-V Battery312
- Charging the 12-V Battery315
- Changing the Main Fuse318
- Changing the ABS Fuses321
- Changing the Fuses of Individual Electrical Power Consumers323
- Changing the Turn Signal Bulb325
- Checking the Headlight Setting327
- Adjusting the Headlight Range328
- Diagnostics Connector330
- Front ACC1 and ACC2330
- ACC1 and ACC2 Rear331
17 Cooling System332
- Checking the Coolant Level in the Compensating Tank333
- Correcting the Coolant Level in the Compensating Tank334
18 Tuning the Engine 18337
- Ride Mode337
- Motorcycle Traction Control (Cornering MTC)338
- Slip Adjustment (Optional)339
- Throttle Response (Optional)340
19 Service Work on the Engine 19341
- Checking the Engine Oil Level341
- Changing the Engine Oil and Oil Filter, Cleaning the Oil Screens342
- Adding Engine Oil346
- Checking the Free Travel of the Clutch Lever348
- Setting the Free Travel of the Clutch Lever349
20 Cleaning, Care350
- Cleaning the Motorcycle350
- Checks and Maintenance Steps for Winter Operation353
21 Storage 21355
- Preparing for Use after Storage356
22 Troubleshooting 22357
23 Technical Data 23361
- Engine361
- Engine Tightening Torques363
- Capacities369
- Engine Oil369
- Coolant369
- Fuel369
- Chassis369
- Electrical System372
- Tires373
- Fork373
- Adventure R373
- Adventure R Rally374
- Shock Absorber376
- Adventure R376
- Adventure R Rally377
- Chassis Tightening Torques379
24 Declarations of Conformity 24389
- Country-Specific Declarations of Conformity392
25 Substances 25393
26 Auxiliary Substances396
27 Standards398
28 Index of Special Terms 28399
- List of Abbreviations400
29 List of Abbreviations401
30 List of Symbols401
- Red Symbols401
- Yellow and Orange Symbols401
- Green and Blue Symbols402
- Index403
