23 TECHNICAL DATA

370

23.5 Electrical system

12-V battery HTZ12A-BS Battery voltage: 12 V

Nominal capacity: 10 Ah

Maintenance-free

Fuse 75011088010 10 A

Fuse 75011088015 15 A

Fuse 75011088025 25 A

Fuse 58011109130 30 A

Low beam/high beam LED

Daytime running light/position light LED

Combination instrument lighting

and indicator lamps

LED

Turn signal RY10W / socket BAU15s 12 V

10 W

Brake/tail light LED

License plate lamp LED
