TECHNICAL DATA 23
377
Weight of rider: 85 … 95 kg (187 … 209 lb.) 95 N/mm (542 lb/in)
Weight of rider: 95 … 105 kg (209 … 231 lb.) 98 N/mm (560 lb/in)
Gas pressure 16 bar (232 psi)
Damper oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 393)
23.9 Chassis tightening torques
Brake fluid reservoir cover, front - 1 Nm (0.7 lbf ft)
Brake fluid reservoir cover, rear - 1.5 Nm (1.11 lbf ft)
Compensating tank cover - 1.1 Nm (0.81 lbf ft)
Nut, valve ISO 10V2 12 Nm (8.9 lbf ft)
Loctite
®
2701â„¢
Remaining screws, chassis EJOTPT
®
K45x12 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x12 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x14 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x16 2 Nm (1.5 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x18 2 Nm (1.5 lbf ft)
Screw, tail light EJOT DELTA PT
®
45x12‑Z 1.5 Nm (1.11 lbf ft)
Socket for electrical accessories - 4 Nm (3 lbf ft)
Throttle valve body hose clamp - 2.8 Nm (2.07 lbf ft)
Remaining nuts, chassis M4 3 Nm (2.2 lbf ft)
