TECHNICAL DATA 23

367

23.3 Capacities

23.3.1 Engine oil

Engine oil 2.8 l (3 qt.) Engine oil (SAE 10W/50)

( p. 392)

23.3.2 Coolant

Coolant 1.60 l (1.69 qt.) Coolant ( p. 391)

23.3.3 Fuel

Total fuel tank capacity, approx. 20 l (5.3 US gal) Super unleaded (ROZ 95)

( p. 393)

Fuel reserve, approx. 3 l (3 qt.)

23.4 Chassis

Frame Lattice frame made of chrome molybdenum steel tub-

ing, powder-coated

Fork (890 ADVENTURE R) WPXPLOR 5548

Shock absorber (890 ADVENTURE R) WPXPLOR 5746

Fork (890 ADVENTURE R RALLY) WPXPLOR PRO 7548
