ELECTRICAL SYSTEM 135
100592-10
– Remove rubber cap and connector from the bulb.
100593-10
– Detach spring bar and remove the bulb from the headlight.
– Position the new bulb in the headlight and attach the spring bar.
Low beam (H7 / socket PX26d) ( p. 192)
Info
The bulb must be positioned with projection in the recess.
– Attach the connector to the bulb and mount the rubber cap.
– Install the headlight mask with the headlight. ( p. 134)
13.10Changing the high beam bulb
Note
Damage to reflector Reduced luminance.
– Grease on the lamp will evaporate due to the heat and be deposited on the reflector. Clean the lamp and keep it free of grease before
mounting.
– Remove the headlight mask with the headlight. ( p. 132)
