CONTROLS 40
5.38Luggage rack plate
B00553-20
The luggage rack plate is located behind the seat.
The base plate of a luggage system (optional) can be attached to the luggage rack plate.
The luggage rack plate may not be loaded with more than the specified weight.
Maximum permissible load
on luggage rack plate
8 kg (18 lb.)
Info
Note the information provided by the luggage manufacturer.
5.39Fuel taps
100524-10
There is a fuel tap on every fuel tank.
Info
The fuel taps must be open during operation.
The fuel taps are only closed when dismantling the fuel tank.
Possible states
• Fuel supply closed – The knurled screws are turned clockwise as far as possible. The
level cannot be compensated and no fuel can flow out of the fuel tank.
• Fuel tap open – The knurled screws are turned counterclockwise as far as possible.
The level can be compensated and the fuel can flow out of the fuel tank.
