SERVICE WORK ON THE CHASSIS 96

– Position the cover with the membrane. Mount and tighten the screws.

10.23Removing the right underride guard

100581-10

– Remove screws . Remove the right underride guard .

10.24Installing the right underride guard

100581-11

– Position right underride guard . Mount and tighten screws .

Guideline

Remaining chassis screws M6 10 Nm (7.4 lbf ft)
