CONTROLS 33
5.26Combination instrument - warning of slippery roads
400894-10
The ice symbol lights up to indicate an increased danger of slippery roads.
The ice symbol appears in the display when the ambient temperature drops below the
specified value.
Temperature 3 °C (37 °F)
The ice symbol goes out in the display when the ambient temperature rises above the
specified value again.
Temperature 4 °C (39 °F)
5.27Combination instrument - coolant temperature indicator
400617-01
The temperature display consists of 12 bars. The more bars that light up, the hotter the
coolant. When the upper bar lights up, all bars in the display begin to flash and the temper-
ature warning lamp lights up.
Possible states
• Engine cold – Up to five bars light up.
• The engine is warm – Six to eleven bars light up.
• Engine hot – All twelve bars flash.
