SERVICE WORK ON THE CHASSIS 81

10.8Removing the radiator guard

100641-10

– Remove screws  and radiator guard .

100642-10

– Pull nuts  off of the radiator.

Tip

Insert the screws into the holes of the radiator guard and mount the nuts. This

ensures that all required parts are available when needed.
